CONCEPT
NINJA 1100 SX
ESSENCE
-
RIDER SUPPORT TECHNOLOGY : IMU-ENHANCED ELECTRONIC PACKAGE
-
ADJUSTABLE REAR MONOSHOCK
-
ELECTRONIC CRUISE CONTROL
-
IMPROVED KAWASAKI QUICK SHIFTER (KQS)
TOP FEATURES
KTRC (KAWASAKI TRACTION CONTROL)
KIBS (KAWASAKI INTELLIGENT ANTI-LOCK BRAKE SYSTEM)
SPECIFICATIONS
VARIANT
STANDARD
SPORT
TOURING
DISPLACEMENT
1,099 CM3
TECHNOLOGY
POWER
-
Engine
Liquid-cooled, 4-stroke In-Line Four DOHC, 16 valves
-
Displacement
1,099 cm3
-
Bore X Stroke
77.0 x 59.0 mm
-
Compression Ratio
11.8:1
-
Fuel Supply
Fuel injection: ø38 mm x 4
-
Lubrication System
Forced lubrication, wet sump
-
Ignition System
Digital
PERFORMANCE
-
Max. power
100.0 kW {136 PS} / 9,000 min-1
-
Max. torque
113.0 N·m {11.5 kgƒ·m} / 7,600 min-1
-
Driving system
Chain
-
Transmission
6-speed, return
-
Primary reduction ratio
1.528 (81/53)
-
Final reduction ratio
2.800 (42/15)
-
Clutch type (Primary)
Wet multi-disc, manual
DETAILS
-
Overall length
2,100 mm
-
Overall width
805 mm
-
Overall height (High/Low position)
1,225 mm / 1,190 mm
-
Wheelbase
1,440 mm
-
Road clearance
135 mm
-
Seat height
835 mm
-
Curb mass
235 kg
-
Dry mass
214 kg
-
Fuel tank capacity
19 litres
-
Suspension: Front
ø41 mm inverted fork with compression and rebound damping and spring preload adjustability
-
Suspension: Rear
Horizontal Back-link, gas-charged rear shock with rebound damping adjustability and remote spring preload adjustability
-
Brakes: Front
Dual semi-floating ø300 mm discs, Dual radial-mount, monobloc, opposed 4-piston
-
Brakes: Rear
Single ø260 mm disc, Single piston
** The curb weight includes all materials and fluids required to operate properly, a full tank of fuel (over 90 percent capacity), and tool kit (if provided).
KAWASAKI CARE: Read the Manual and all warnings on the product. Always wear a helmet, eye protection, and appropriate clothing for riding conditions. Never drive under the influence of drugs or alcohol. Follow the maintenance schedule in your Manual. © 2022 Edaran Modenas Sdn Bhd. All Rights Reserved.
Specifications are subject to change.
