Engine

Liquid-cooled, 4-stroke In-Line Four, DOHC, 16 valves

Bore X Stroke

67.0 x 45.1 mm

Displacement

636 cm3

Compression Ratio

12.9:1

Fuel Supply

Fuel injection: ø38 mm x 4 with oval sub-throttle

Lubrication System

Forced lubrication, wet sump

Starting System

Electric

Ignition System

Digital

Max. power

91.0 kW {124 PS} / 13,000 min-1

Max. power with Ram Air

95.2 kW {129 PS} / 13,000 min-1

Max. torque

69.0 N·m {7.0 kgƒ·m} / 10,800 min-1

Transmission

6-speed, return

Clutch type (Primary)

Wet multi-disc, manual

Suspension: Front

ø41 inverted fork (SFF-BP) with rebound and compression damping and spring preload adjustability, and top-out springs

Suspension: Rear

Bottom-Link Uni Trak, gas-charged shock with piggyback reservoir, compression and rebound damping and spring preload adjustability

Brake; Front

Dual semi-floating ø310 mm discs (Effective diameter: ø275 mm) Dual radial-mount, monobloc, opposed 4-piston

Brake: Rear

Single ø220 mm disc (Effective diameter: ø186 mm) Single-bore pin-slide

Overall length

2,025 mm

Overall width

710 mm

Overall height

1,105 mm

Wheelbase

1,400 mm

Road clearance

130 mm

Seat height

830 mm

Curb mass

198 kg

Fuel tank capacity

17 litres
