Engine Type

Liquid-cooled, 4-stroke In-Line Four DOHC, 16 valves

Bore X Stroke

73.4 x 56.0 mm

Displacement

948 cc

Compression Ratio

11.8:1

Fuel Supply

Fuel injection: 36 mm x 4

Lubrication System

Forced lubrication, wet sump

Starting System

Electric

Ignition System

Digital

Max. Power

91.0 kW / 9,500 rpm

Max. Torque

97.4 N·m / 7,700 rpm

Frame Type

Trellis, High-tensile Steel

Front Suspension

41 mm inverted fork with rebound damping and spring preload adjustability

Rear Suspension

Horizontal Back-link, gas-charged shock with rebound damping and spring preload adjustability

Wheel Travel (Front/Rear)

120 mm / 140 mm

Caster (Rake Angle)

24.7°

Trail

110 mm

Steering Angle (left/right)

33° / 33°

Tyre (Front)

120/70ZR17M/C (58W)

Tyre (Rear)

180/55ZR17M/C (73W)

Front Brakes

Dual semi-floating 300 mm discs (Effective diameter: 264 mm)

Front Caliper

Dual radial-mount, opposed 4-piston

Rear Brakes

Single 250 mm disc (Effective diameter: 216 mm)

Rear Caliper

Single-piston

Overall Length

2,065 mm

Overall Width

830 mm

Overall Height

1,075 mm

Wheelbase

1,450 mm

Road Clearance

145 mm

Seat Height

810 mm

Curb Mass

213 kg

Dry Mass

193 kg

Fuel Capacity

17 litres

Driving System

Chain

Transmission

6-speed, Return Shift

Primary Reduction ratio

1.627 (83/51)

Final Reduction ratio

2.933 (44/15)

Clutch Type (Primary)

Wet Multi-Disc, Manual
